PET Blowing Machine

Full automatic PET bottle blowing machine  0.1-2L

Full automatic PET bottle blow molding machine

Model No.: SC-F2, SC-F4, SC-F6Origin: Taizhou,China
Port: Ningbo or ShanghaiBrand: Sinco
Delivery: 30-45 daysPacking: Wooden case
Transportation: By seaPayment: T/T or L/C

High Speed Full Automatic PET Bottle Making Machine

SC-F serious Fully automatic PET bottle maker machine is the most stable automatic water bottle machine. It can blow bottles with maximum volume of the products is 2.0L.This machine is suitable for producing PET bottles for mineral water, pure water, juice, carbonated water, cooking oil in round or square shapes.
This kind of blowing machine can blow bottle from 50-2000ml with capacity 2000-6000 bottles per hour.

The advantages

  1. Automatic perform input and ready bottle output system.
    Machine adopt with the overall structure of super-standard anti-vibration design, high-speed operation state of the machine will shake down to a minimum.
  2. Machine adopts modular assembly method, greatly decrease the local amendments due to technological improvements when the machine is on processing.
  3. The structure of machine oven adopt the international most advanced energy-saving technology of infrared radiation heating, temperature control with automatic negative feedback, closed-loop regulation model.
  4. Automation controlling item adopts international high-end computer system, heating, collecting and measuring perform temperature with simulation input and output module.
  5. Man-machine interface displays current production situation, available for on line switching, parameter modification and production accounting, with automatic alarm, automatic fault detection and diagnose.

Technical Specification of Full automatic PET bottle bottle blow molding machine

SystemsItemUnitSC-F2SC-F4SC-F6
Bottle Spec.Number of cavitycavity246
Theoretical Outputpcs/hour2000-25004000-50005500-7000
Max.container volumeLtr2.02.01.5
Max.neck diametermm454538
Max.container diametermm100100100
Max.container heightmm340340340
Electrical systemNumber of lamppcs283248
Max.heating powerkw222638
Installation powerkw253045
Actual power consumptionkw122030
Machine Spec.Main Machine sizem1.9×1.6×2.02.5×2.0.2.04.2×2.0x2.0
Main machine weightkg160023005000
Auto preform loader sizem1.5×1.0x2.02.0×1.2×2.02.0×1.2×2.2
Auto preform loader weightkg160200260
